Energy, Oil & Gas
Corrosion- and pressure-resistant components for hostile service
Valve bodies, wellhead components, pump parts and flow-control hardware in duplex, super duplex, Inconel and 17-4PH — pressure-tested and certified for service where failure is not recoverable.
Typical requirements
- NACE MR0175 / ISO 15156 compliance
- Hydrostatic testing with certificates
- NDT: RT, UT, MPI and dye penetrant
- EN 10204 3.1 / 3.2 certificates
- Manufacturing data book compilation
Components we machine
Materials that survive the environment
Sour service, chlorides, high temperature and 700-bar pressure narrow the material list quickly. We machine duplex 2205, super duplex 2507, Inconel 625 and 718, Monel, 17-4PH and F51/F55 forgings, with NACE MR0175 / ISO 15156 compliant material where the specification calls for it.
These are difficult materials. Work hardening, poor thermal conductivity and abrasive inclusions all shorten tool life, and cutting data has to be right the first time. Our process sheets for each alloy family are built from real production data, not catalogue starting points.
Pressure integrity
Bodies and closures are hydrostatically tested to 1.5× working pressure with the test record supplied. Sealing surfaces are ground or lapped and inspected for scratches under magnification, because a 0.02 mm defect across an O-ring groove is a leak path.
Weld and NDT support
Welding to ASME IX qualified procedures, with radiographic, ultrasonic, magnetic particle and dye penetrant inspection through accredited partners. PMI verification confirms the alloy actually delivered matches the alloy specified.
Documentation for certification
EN 10204 3.1 and 3.2 material certificates, hydrostatic test reports, NDT reports, heat treatment records and dimensional reports, compiled into a manufacturing data book where your end client requires one.
Working in this sector?
We can share relevant references and quality documentation under NDA.
- Reviewed by a manufacturing engineer
- NDA available before file exchange
